High Flexibility SMT screen printer
Description
Designed with ease of use, high-end performance and low cost of ownership in mind, the high flexibility screen printer utilises the most advanced drive control technology available, including 1 micron resolution linear encoders on all axes. A suite of intuitive software enables total control of the printing process.
The printers are fully equipped, as standard, with many features such as automatic rail width adjust, auto stencil loading, a fully programmable Under Stencil Cleaner and even automatic stencil paste inspection.
In fact, everything you need to complete the SMT screen print process without exception or compromise.
The PCB transport system includes a fully programmable board stop and employs pneumatically controlled foil PCB clamping.
The system is SMEMA compatible to ease integration with fully automated SMT production lines.
Features / Benefits
Vision System
Dual Roving camera (DRc) technology precisely aligns the board and stencil, and checks for solder paste presence on the stencil before printing.
SmartCal
SmartCal, a zero-cost straightforward calibration facility that lets operators validate the process in 30 seconds or less. SmartCal helps to maximise and maintain your process window, delivering optimum performance for the operational life of the printer.
Laser Tooling
The laser tooling option is an invaluable aid to quickly and accurately position magnetic support pins in the correct locations for double sided PCBs.
Auto Dispense (ADu+)
The EP710 screen printer can deploy the unique Automatic Dispense Unit (ADu and ADu+) to dispense a wide range of media including paste and glue.
S-Track Labeling
S-Track allows the placement of barcode labels anywhere on the PCB after printing for the EP700 series screen printers.
Introduces traceability earlier in the line.
Technical Data
| EP700 | EP710 | |
|---|---|---|
| Max Board Size | 610mm x 515mm | 610mm x 515mm |
| Min Board Size | 45mm x 45mm | 45mm x 45mm |
| Machine alignment repeatability | 12.5μm @ 6 sigma 2Cpk | 12.5μm @ 6 sigma 2Cpk |
| Full process repeatability | 20μm @ 6 sigma 2Cpk | 20μm @ 6 sigma 2Cpk |
| X/Y PCB alignment | +/- 5mm | +/- 5mm |
| Squeegee pressure | 1Kg to 20Kg | 1Kg to 20Kg |
| Print speed | 5mm/sec to 250mm/sec | 5mm/sec to 250mm/sec |
| Clamping thickness | 0.2mm to 8mm | 0.2mm to 8mm |
| ADu+ | No | Yes |
| Dimensions | 1224 W x 1591 D x 1285 H | 1224 W x 1591 D x 1285 H |
Options / Accessories
Add-on modules
- Automatic Dispensing Unit
- S-Track Barcode labelling
- Laser Tooling
