ii-A1

The Versatile Module
All the capability of the ii-A range in a compact space, modular, enabling you to build your line, with speeds up to 15,000

ii-A1

Description

Intelligent

Industry 4.0 and IPC CFX enabled

Flexible

High Feeder count and fast changeovers

Compact

Small in size, big on specifications

The ii-A1 multi-functional SMT placement machine delivering unparalleled flexibility across a broad range of component sizes.

The ii-A1 is a versatile machine featuring a single Tornado turret head with eight or twelve nozzles, 162 feeder positions and 2 internal matrix trays, all in a compact footprint, configurable for specific SMT assembly duties or as a fully featured stand alone module offering placement speeds up to 15,000cph.

Despite the compact module format, ii-A1 can handle boards up to 1m (39″) in length.

ii-A1 in operation

Internal Matrix Trays

Rotary Turret Head

8 or 12 smart nozzles

Electrical Test

Electrical Test

*Optional extra

Features / Benefits

ii-A1
Rotary Turret Head

The ii-A1 has a single rotary turret head with 8 or 12 smart nozzles

Electrical Test
Electrical Tester

Electrical component testing with independently verifiable calibration (UKAS / NIST / PTB…etc)

No Component Limitations

Every nozzle position can place all and any component types, for real line balancing and no limitations

3DPS (3D Positioning System)

Advanced solution for height compensation control during the pick and place process.

Internal Matrix Trays

The ii-A1 supports 2 internal matrix trays to support Jedec and loose components

Range of feeders / nozzles

Odd form & smart nozzle banks
* Optional extras

Technical Data

Component Range 01005 to 50mm x 50mm
(With fixed camera) 99mm x 99mm (more on demand)
Max Component Height 34mm (31mm with 12 nozzles)
Feeder: Tapes 4mm to 104mm
Feeder: Capacity 162 positions x 8mm
Feeder: Internal 2 x Matrix trays
Placement Heads 1 x 8 or 12 nozzle Tornado head
Max PCB Size 1070mm x 715mm
Max Placement Rate 14,000cph (15,390 with 12 nozzles)
Placement Accuracy 22um (QFPS) TO 46um (CHIPS) @ 3 Sigma

Options / Accessories

Machine

  • Fixed upward looking camera for larger and very fine pitch components
  • Motorization of conveyor width adjustment
  • HeavyPCB kit for conveyor (10 kgs)
  • Wide pcb kit 715mm (no feeder at the rear)
  • Rear operating station

Software and Programming

  • Offline preparation
  • Stock Management
  • Full Traceability
  • PROMON Software
  • Keyboard
  • Mouse

Feeders

  • Barcode feeders
  • Bulk feeders
  • Ball feeders for BGAs
  • Flux feeder & PoP processing
  • Tray sequencer
